Template for design details
Okay so you got your main drawings ready. But what about the smaller details? We all know these require a separate lineweight system that caters to smaller drawing scales. This template makes it a breeze to get your zoomed in drawings print ready in no time!
In addition to a reference drawing, the download includes layer guides with layer properties listed, title sheet, a corresponding .ctb file and even font files to make your drawings crystal clear, legible and easy-to understand.
Note: Dimensions in the files may not be 1:1 & may be scaled up or down according to the scale of the detail. The details provided are only for reference; be sure to scale & use your details according to your requirement.
'Design Details Drawing' Template
Simple Instructions:
- Install the fonts into your PC.
- Complete the drawing according to the layers in the file. Layer descriptions make it easy to know what to put into each layer.
- Edit the title sheet to your requirements. Title sheet works for A1-A4 sizes.
- Copy-paste the .ctb file into your software's plot style location.
- Select the coresponding .ctb file during plotting.
- Voila! And your work is done!
File Type:
.zip file consisting of TrueType font files, .ctb plot style and .dwg CAD drawing.
File Size:
285 KB
